Ceratizit WTX-CHANGE.12,50-12,99.R.1D.HB.14 Indexible Insert 1091112500 (0727566)


Price:
Sale price$255.44
Stock:
Not in stock - Available to order

Description

Material Number: 1091112500

Article Number: 10911125

Ceratizit is a large tooling company based in Luxembourg (Europe).

This product is priced singly and comes in packs of 1.

Please note that the actual item may not be/look exactly the same as shown in the item picture(s).

Properties
Name Ceratizit WTX-CHANGE.12,50-12,99.R.1D.HB.14 Indexible Insert 1091112500 (0727566)
EDP # 0727566
Workpiece Material(s) Steel (Blue) Cast Iron (Red) Aluminum (Green) Steel (Blue) Stainless Steel (Yellow) HiTemp Alloy (Orange) All Materials (White)
Weight (1 pc.) 3.0 oz 94.9 g
Cutting edge Ø - range / DC 0.4921" - 0.5114" 12.500 - 12.990 mm
Mounting spigot diameter / DCONMS 0.5512" 14.000 mm
Overall length / OAL 3.1890" 81.000 mm
Length chip flute / LCF 1.1417" 29.000 mm
Usable length / LU 0.5118" 13.000 mm
Protruding length / LPR 1.4173" 36.000 mm
torque moment 1 Nm


Suitable Materials:

Property imageProperty imageProperty imageProperty imageProperty imageProperty image

Background Information:

Company History:

The company is a result of the merging of Metallwerk Plansee GmbH (Austria, 1921, later 'Plansee Tizit') and CERAMETAL (Luxembourg, 1931). The name Ceratizit was created by combining their names in 2002. Both founding companies originally produced molybdenum wire and tungsten lightbulb filaments, and were pioneers in commercial cemented tungsten carbide (since as early as 1929!) and their metal working / cutting tool product lines currently add up to over 80,000 items!
