Description
zsgmini.zs.osb.70.100 centric vice
Mat No: 8091207100, Article No: 8091207100
Ceratizit Group is an industry leader in solid carbide cutting tool technology.
ZSG Mini is a small modular workholding system
Please note that the actual item may not be/look exactly the same as shown in the item picture(s).
| Properties | ||
|---|---|---|
| Name | Ceratizit ZSGMINI.ZS.OSB.70.100 8091207100 (0650374) | |
| EDP # | 0650374 | |
| Weight | 39.6 oz | 1124 g |
| A | 2.7559 inch | 70 mm |
| B | 7 - 77 mm | |
| C | 0.7874 inch | 20 mm |
| E | 1.6535 inch | 42 mm |
| G | 3.9370 inch | 100 mm |
| Drive size DRVS/SW | 0.4331 inch | 11 mm |
| Maximum clamping force MXC/Clamping force | 16 kN | |
