Description
WTX-HFDS.6,5.R.5D.IK.HA DPX14S SOLID CARBIDE TWIST DRILL Four fluted high-feed drill Specialises in steel processing Has four spiral coolant holes Innovative cutting edge geometry guarantees high positioning accuracy Outstanding drilling quality in terms of tolerance, surface finish and position
Mat No: 1079806500, Article No: 1079806500
Ceratizit Group is an industry leader in solid carbide cutting tool technology.
Solid Carbide Twist Drill
'D' form indicates that the tool is intended for drilling/plunging, and will not cut laterally.
Please note that the actual item may not be/look exactly the same as shown in the item picture(s).
| Properties | ||
|---|---|---|
| Name | Ceratizit WTX-HFDS.6,5.R.5D.IK.HA DPX14S SOLID CARBIDE TWIST DRILL 1079806500 (0662137) | |
| EDP # | 0662137 | |
| Workpiece Material(s) | Steel (Blue) Stainless Steel (Yellow) Cast Iron (Red) Aluminum (Green) Composites (Black) | |
| Weight | 0.0 oz | 0 g |
| Cutting diameter DC/d1 m7 | 0.2559 inch | 6.5 mm |
| Overall length OAL/l1 | 4.0157 inch | 102 mm |
| Length chip flute LCF/l2 | 2.3228 inch | 59 mm |
| Mounting spigot diameter DCONMS/d2 h6 | 0.3937 inch | 10 mm |
| Shank length LS/l4 | 1.5748 inch | 40 mm |
| Usable length LU/l3 | 1.8504 inch | 47 mm |
Application & Properties:
Suitable Materials:
