Description
WTX-HFDS.14,5.R.5D.IK.HA DPX14S SOLID CARBIDE TWIST DRILL Four fluted high-feed drill Specialises in steel processing Has four spiral coolant holes Innovative cutting edge geometry guarantees high positioning accuracy Outstanding drilling quality in terms of tolerance, surface finish and position
Mat No: 1079814500, Article No: 1079814500
Ceratizit Group is an industry leader in solid carbide cutting tool technology.
Solid Carbide Twist Drill
'D' form indicates that the tool is intended for drilling/plunging, and will not cut laterally.
Please note that the actual item may not be/look exactly the same as shown in the item picture(s).
| Properties | ||
|---|---|---|
| Name | Ceratizit WTX-HFDS.14,5.R.5D.IK.HA DPX14S SOLID CARBIDE TWIST DRILL 1079814500 (0662154) | |
| EDP # | 0662154 | |
| Workpiece Material(s) | Steel (Blue) Stainless Steel (Yellow) Cast Iron (Red) Aluminum (Green) Composites (Black) | |
| Weight | 0.0 oz | 0 g |
| Cutting diameter DC/d1 m7 | 0.5709 inch | 14.5 mm |
| Overall length OAL/l1 | 5.5906 inch | 142 mm |
| Length chip flute LCF/l2 | 3.5827 inch | 91 mm |
| Mounting spigot diameter DCONMS/d2 h6 | 0.6299 inch | 16 mm |
| Shank length LS/l4 | 1.8898 inch | 48 mm |
| Usable length LU/l3 | 2.874 inch | 73 mm |
Application & Properties:
Suitable Materials:
