CERATIZIT WTX-HFDS.15,0.R.3D.IK.HA DPX14S SOLID CARBIDE TWIST DRILL 1079715000 (0662226)


Price:
Sale price$363.18
Stock:
Not in stock - Available to order

Description

WTX-HFDS.15,0.R.3D.IK.HA DPX14S SOLID CARBIDE TWIST DRILL Four fluted high-feed drill Specialises in steel processing Has four spiral coolant holes Innovative cutting edge geometry guarantees high positioning accuracy Outstanding drilling quality in terms of tolerance, surface finish and position

Mat No: 1079715000, Article No: 1079715000

This product comes in packages of 1

Ceratizit is a large tooling company based in Luxembourg (Europe). The company is a result of the merging of Metallwerk Plansee GmbH (Austria, 1921, later 'Plansee Tizit') and CERAMETAL (Luxembourg, 1931). The name Ceratizit was created by combining their names in 2002. Both founding companies originally produced molybdenum wire and tungsten lightbulb filaments, and were pioneers in commercial cemented tungsten carbide (since as early as 1929!) and their metal working / cutting tool product lines currently add up to over 80,000 items!

Please note that the actual item may not be/look exactly the same as shown in the item picture(s).

Properties
Name CERATIZIT WTX-HFDS.15,0.R.3D.IK.HA DPX14S SOLID CARBIDE TWIST DRILL 1079715000 (0662226)
EDP # 0662226
Workpiece Material(s) All Materials (White)
Weight 0.0 oz 0.0 g
Cutting diameter DC/d1 m7 0.5906 inch 15 mm
Overall length OAL/l1 4.8425 inch 123 mm
Length chip flute LCF/l2 2.874 inch 73 mm
Mounting spigot diameter DCONMS/d2 h6 0.7087 inch 18 mm
Shank length LS/l4 1.8898 inch 48 mm
Usable length LU/l3 2.0079 inch 51 mm
