Zedaro Pre-Assembled ROTA-S PLUS 2.0 160-42 on System3R Macro Magnum 156mm Pallet with Drawbar (0731452)

Zedaro Pre-Assembled ZSG-4.1.125.160.MBG Centric Vice on System3R Macro Magnum 156mm Pallet with Drawbar.

Clamping force: max. 35 kN

This assembly is comprised of the following components:

(1 pc) Schunk ROTA-S Plus 2.0 160-42 Z145-SFG (Chuck) 0819001 (0731655)

(1 set) Schunk SHF 160, Hard Stepped Top Jaws 0155100 (0731657)

(1 pc) System 3R - 3R-681.51-SA Macro Magnum Pallet 156mm Diameter (0659616)

(1 pc) System 3R - 3R-605.1EE Drawbar - Macro for Automatic Chuck (0659613)

(2 pc) Dowel Pin

(8 pc) SHCS
