Description
The 'Purple' line of tooling is designed specifically for cutting wrought titanium alloys.
The 'Swiper' line is a tight-tolerance 3D finishing tool which has as many flutes as possible in order to allow for very high feed rates while removing a thin layer of material. These tools should be used last in order to achieve the perfect final form and finish.
'R' form tools are the classic end-mill shape, straight sides (flanks) with corners ranging from sharp (flat tip) to completely round (ball tip). This form is the most common of all, and good for almost everything.
| Tool Properties | ||
|---|---|---|
| Name | PURSWIPER-9.525R4.76-14.0HAW25.4-N28AB1 | |
| EDP # | 0736154 | |
| Material | Titanium | Application | Finish 3D Fine Under Nominal (Swiper) |
| Form | End Mill - Ball | |
| Cutting Diameter | 0.3750" | 9.525 mm |
| Corner Radius | 0.1874" | 4.760 mm |
| Taper per Side | 0.0° | |
| Length of Cut | 0.3748" | 9.520 mm |
| Reach | 0.5512" | 14.000 mm |
| Minimum Extension | 1.0" | 25.4 mm |
| Maximum Extension | 2.1" | 52.1 mm |
| Shank Diameter h6 | 0.5000" | 12.700 mm |
| Overall Length | 2.8" | 72 mm |
| Cutting Edges | 8 | |
| Tolerance Class | null | |
