Ceratizit CNGM 190612FN-27 H10T CoreLine Carbide Turning indexable Insert 7023965600 (0743445)
Ceratizit CNGM 190612FN-27 H10T CoreLine Carbide Turning indexable Insert 7023965600 (0743445)
Couldn't load pickup availability
Ceratizit Article Number: 7023965600
Ceratizit Material Number: 72622
Ceratizit is a large tooling company based in Luxembourg (Europe).
This product is priced singly and comes in packs of 1.
Please note that the actual item may not be/look exactly the same as shown in the item picture(s).
| Properties | ||
|---|---|---|
| Name | Ceratizit CNGM 190612FN-27 H10T CoreLine Carbide Turning indexable Insert 7023965600 | |
| EDP # | 0743445 | |
| Weight (1 pc.) | 1.0 oz | 25.2 g |
| Product-Carbon-Footprint | C | |
| designation | 190612FN | |
| Corner radius / RE | 0.0472" | 1.200 mm |
| Cutting edge length / L | 0.7598" | 19.300 mm |
| Insert thickness / S | 0.2500" | 6.350 mm |
| Fixing hole diameter / D1 | 0.3126" | 7.940 mm |
| Inscribed circle diameter / IC | 0.7500" | 19.050 mm |
| 643FN | ||
| Size | 19.0000" | 482.600 mm |
| Designation | CNGM 190612EN | |
| Chip breaker (Ceratizit) / CBMD | -27 | |
| Coating name / Grade (Ceratizit) / COATN | Uncoated | |
Company History:
The company is a result of the merging of Metallwerk Plansee GmbH (Austria, 1921, later 'Plansee Tizit') and CERAMETAL (Luxembourg, 1931). The name Ceratizit was created by combining their names in 2002. Both founding companies originally produced molybdenum wire and tungsten lightbulb filaments, and were pioneers in commercial cemented tungsten carbide (since as early as 1929!) and their metal working / cutting tool product lines currently add up to over 80,000 items!
