Ceratizit SCR.H-TO.8,0.45°.Z4.R1,0.HA.L.IK TI1200 CoreLine Torus Face Milling Cutter 52609080 (0770778)
Ceratizit SCR.H-TO.8,0.45°.Z4.R1,0.HA.L.IK TI1200 CoreLine Torus Face Milling Cutter 52609080 (0770778)
Couldn't load pickup availability
Ceratizit Article Number: 52609080
Ceratizit Material Number: 5260908000
Ceratizit is a large tooling company based in Luxembourg (Europe).
Product discontinued! Unavailable if out of stock.
This product was priced singly and came in packs of 1.
Please note that the actual item may not be/look exactly the same as shown in the item picture(s).
| Properties | ||
|---|---|---|
| Name | Ceratizit SCR.H-TO.8,0.45°.Z4.R1,0.HA.L.IK TI1200 CoreLine Torus Face Milling Cutter 52609080 | |
| EDP # | 0770778 | |
| Weight (1 pc.) | 1.0 oz | 42.2 g |
| Cutting diameter / DC -0.04 mm | 0.3150" | 8.000 mm |
| Corner radius / RE | 0.0394" | 1.000 mm |
| 3D radius | 0.0394" | 1.000 mm |
| Depth of cut maximum / APMX | 0.7480" | 19.000 mm |
| Neck Diameter / DN | 0.3031" | 7.700 mm |
| Head length / LH | 0.9783" | 24.850 mm |
| L6 | 0.9843" | 25.000 mm |
| Protruding length / LPR | 1.0630" | 27.000 mm |
| Overall length / OAL | 2.4803" | 63.000 mm |
| Mounting spigot diameter / DCONMS h5 | 0.3150" | 8.000 mm |
| T max. | 0.0118" | 0.300 mm |
| Profile radius 2 / PRFRAD2 | 0.1535" | 3.900 mm |
| Profile radius 1 / PRFRAD1 | 0.0394" | 1.000 mm |
| Peripheral effective cutting edge count / ZEFP | 4.0000" | 101.600 mm |
| Coating name / Grade (Ceratizit) / COATN | Ti1200 | |
| Product-Carbon-Footprint | F | |
| Machining process - Main Application | Form milling | |
Company History:
The company is a result of the merging of Metallwerk Plansee GmbH (Austria, 1921, later 'Plansee Tizit') and CERAMETAL (Luxembourg, 1931). The name Ceratizit was created by combining their names in 2002. Both founding companies originally produced molybdenum wire and tungsten lightbulb filaments, and were pioneers in commercial cemented tungsten carbide (since as early as 1929!) and their metal working / cutting tool product lines currently add up to over 80,000 items!
