HAIMER MILL Power Series - Multifunction End Mill, 2F, w/ Straight shank, Angle = 120° E1012NNH0400W120DA (0841575)
HAIMER MILL Power Series - Multifunction End Mill, 2F, w/ Straight shank, Angle = 120° E1012NNH0400W120DA (0841575)
Couldn't load pickup availability
Haimer Part Number: E1012NNH0400W120DA
HAIMER is a global leader in tool holding, balancing, and presetting technology. Founded in 1977 and headquartered in Igenhausen, Germany, HAIMER offers premium shrink fit chucks, tool balancing machines, and precision tool holders trusted in high-performance machining environments worldwide.
This product is priced singly and comes in packs of 1.
Please note that the actual item may not be/look exactly the same as shown in the item picture(s).
| Properties | ||
|---|---|---|
| Name | HAIMER MILL Power Series - Multifunction End Mill, 2F, w/ Straight shank, Angle = 120° E1012NNH0400W120DA | |
| EDP # | 0841575 | |
| Weight (1 pc.) | 0.3 oz | 9.0 g |
| Angle | 120 | |
| Corner design | W | |
| Cutting edge diameter / D1 | 0.1570" | 4.000 mm |
| HAIMER Coating | A | |
| Number of cutting edges / Z | 2 | |
| Shank diameter / D | 0.1570" | 4.000 mm |
| Shank version | Straight shank | |
Product Features:
- HAIMER MILL - E1012NN/NL Multifunction End Mill
- Solid carbide end mill
- Multifunctional tool
- Center spot
- Circumference cutting
- Multifunction end mill for chamfering, slotting, trimming and centering
- Cone angle 60/90/120/142°
- Center spot 142°
- For almost all materials
- Especially suitable for center spotting
- Suitable for chamfering, side milling and slotting
-
- Spot
- Teeth 2
- Straight shank (HA)
- Helix angle 20°
- Steel All types of steel and cast steel, with the exception of steel with an austenitic structure
- Stainless steel Stainless austenitic steel and austenitic-ferritic steel and cast steel
- Cast iron Grey cast iron, cast iron with spheroidal graphite, malleable cast iron, cast iron with vermicular graphite
- High temperature alloys and titanium alloys Heat resisting special alloys based on iron, nickel and cobalt, titanium and titanium alloys
- NF metals Aluminium and other non-ferrous metals, non ferrous materials
- Hard materials Hardened steel, hardened cast iron materials, chilled cast iron
- Feed direction (Side milling, Ramping, Drilling)
- V-slotting
- Contouring
- Chamfering
- Side milling
- Emulsion
- Cold air
- Dry machining
- Minimal lubrication
Company History:
Family-owned since 1977, HAIMER has grown from a precision parts specialist into a global tooling solutions supplier with operations across Europe, North America, and Asia.
