Zedaro GRNGLIDER-2.000R0.10-CUSTOMLEN-G25CG1 (0842233)
Zedaro GRNGLIDER-2.000R0.10-CUSTOMLEN-G25CG1 (0842233)
Couldn't load pickup availability
Zedaro UID: 0842233
Zedaro is a premium tooling brand from Canada.
This product is priced singly and comes in packs of 1.
Please note that the actual item may not be/look exactly the same as shown in the item picture(s).
| Properties | ||
|---|---|---|
| Name | Zedaro GRNGLIDER-2.000R0.10-CUSTOMLEN-G25CG1 | |
| EDP # | 0842233 | |
| Workpiece Material(s) | Aluminum (Green) | |
| Weight (1 pc.) | 1.0 oz | 31.0 g |
| Cutting Diameter | 0.0787" | 2.000 mm |
| Corner Radius | 0.0039" | 0.100 mm |
| Application | Finish 3D Milling >20k RPM (Glider) | |
| Form | R-TORUS | |
| Shank Diameter (h5) | 0.2500" | 6.350 mm |
| Cutting Edges | 2 | |
| Tolerance Class | h6 | |
| Length of Cut | 0.0591" | 1.500 mm |
| Overall Length | 2.5000" | 63.500 mm |
| Reach | 0.3150" | 8.000 mm |
| Minimum Extension | 1.0000" | 25.400 mm |
| Maximum Extension | 2.0000" | 50.800 mm |
Product Features:
- The 'Green' line of tooling is designed specifically for cutting wrought aluminum alloys (Non-Ferrous)
- The 'Glider' line is a tight-tolerance 3D finishing tool intended for machine tools with spindle speeds greater than 20K rpm and which can be used for almost anything.
- 'R' form tools are the classic end-mill shape, straight sides (flanks) with corners ranging from sharp (flat tip) to completely round (ball tip). This form is the most common of all, and good for almost everything.
- This is a custom design which does not follow standard proportions.
Company History:
Zedaro has been producing cutting edge technology for over a decade.
